FYC 40 TF | SKF | Flanged Ball Bearing Units 40MM

₹ 6,080.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

FYC 40 TF

Original Equipment Manufacturer

SKF

Descripción
Attribute Value / Detail
Model / Designation FYC 40 TF
Bearing Unit Type 4‑bolt round / flanged ball bearing unit
Bore (inner diameter), d 40 mm
Housing material Cast iron
Bolt center to center (J) 84.90 mm
Flange bolt circle diameter 120 mm
Overall housing length / unit length 145 mm
Width through bore (insert width) 49.2 mm
Radial dynamic load rating, C 30.7 kN
Radial static load rating, C₀ 19.0 kN
Limiting speed 4,800 rpm
Seals / Shielding Seals / flingers on both sides (standard)
Locking / securing method Set screw locking
Weight ~1.85 kg
SKF

FYC 40 TF | SKF | Flanged Ball Bearing Units 40MM

₹ 6,080.00
Attribute Value / Detail
Model / Designation FYC 40 TF
Bearing Unit Type 4‑bolt round / flanged ball bearing unit
Bore (inner diameter), d 40 mm
Housing material Cast iron
Bolt center to center (J) 84.90 mm
Flange bolt circle diameter 120 mm
Overall housing length / unit length 145 mm
Width through bore (insert width) 49.2 mm
Radial dynamic load rating, C 30.7 kN
Radial static load rating, C₀ 19.0 kN
Limiting speed 4,800 rpm
Seals / Shielding Seals / flingers on both sides (standard)
Locking / securing method Set screw locking
Weight ~1.85 kg
