SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC
LC1K1210M7 | SCHNEIDER ELECTRIC | TeSys K Vontactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 220...230 V AC Coil
₹ 9,093.98
LC1K1210M7 | SCHNEIDER ELECTRIC | TeSys K Vontactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 220...230 V AC Coil
está agotado y se enviará tan pronto como vuelva a estar disponible.
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
LC1K1210M7 | SCHNEIDER ELECTRIC | TeSys K Vontactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 220...230 V AC Coil
LC1K1210M7 | SCHNEIDER ELECTRIC | TeSys K Vontactor - 3P - AC-3 <...
LC1K1210M7 | SCHNEIDER ELECTRIC | TeSys K Vontactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 220...230 V AC Coil
está agotado y se enviará tan pronto como vuelva a estar disponible.
Manufacturer Part Number (MPN)
LC1K1210M7
Original Equipment Manufacturer
SCHNEIDER ELECTRIC
Descripción
Device Type
3‑pole contactor, 3 NO main contacts
Rated Current AC‑3
12 A (≤ 440 V AC)
Rated Current AC‑1
20 A (≤ 440 V AC)
Motor Power (AC‑3)
~3 kW @ 230 V; 5.5 kW @ 380–415 V; up to 4 kW @ 660–690 V
Control (Coil) Voltage
220…230 V AC, 50/60 Hz
Auxiliary Contacts
1 NO (instantaneous)
Rated Insulation Voltage (Ui)
690 V AC (IEC, UL, CSA)
Impulse Withstand Voltage (Uimp)
8 kV, Overvoltage Category III
Thermal Current (Ith)
20 A for power, 10 A for signalling circuit (≤ 50–60 °C)
Making Capacity (Irms)
144 A AC (power), 110 A AC (signalling)
Breaking Capacity
110 A @ 440 V; 80 A @ 500 V; 70 A @ 660‑690 V (IEC)
Short‑Time Withstand (Icw)
115 A for 1 s, 105 A for 5 s, down to ~50 A for ≥3 min
Fuse Rating
25 A gG (power), 10 A gG (signalling)
Mounting & Terminals
DIN‑rail or panel; screw‑clamp terminals (0.34–4 mm² cables)
Dimensions (H×W×D)
58 × 45 × 57 mm
Weight
≈ 0.18 kg
Operating Temperature
−25 °C to +50 °C (storage −50 °C to +80 °C)
Operating Frequency (max)
3600 cycles/hour
Mechanical Durability
10 million cycles (electrical ~1.3 M @ 12 A AC‑3)
Certifications
IEC 60947‑4‑1 / UL 508 / CSA, Green Premium, RoHS/REACH compliant
