LV429632 | SCHNEIDER ELECTRIC | Circuit breaker Compact NSX100F, 36 kA at 415 VAC, TMD trip unit 63 A, 3 poles 3d

₹ 9,897.10

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LV429632

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Descripción
Manufacturer Schneider Electric (ComPact NSX Series)
Device Type Circuit Breaker, fixed, 3‑pole (3P, 3d)
Series / Range ComPact NSX100F
Rated Current (In) 63 A at 40 °C (trip unit TM‑D)
Poles Description 3P, protected poles 3t
Rated Operational Voltage (Ue) 690 V AC 50/60 Hz
Rated Insulation Voltage (Ui) 800 V AC
Impulse Withstand Voltage (Uimp) 8 kV
Breaking Capacity (Icu) 36 kA @ 380/415 V AC; also 35 kA @ 440 V, 22 kA @ 525 V, 8 kA @ 660/690 V (IEC‑compliant)
Service Breaking Capacity (Ics) 36 kA @ 380/415 V (also 35 kA @ 440 V, 11 kA @ 525 V)
Trip Unit TM‑D, thermal‑magnetic with Long‑time & Instantaneous (LI)
Adjustability Long‑time pick‑up Ir adjustable (0.7…1 × In)
Durability Mechanical: 50,000 cycles; Electrical: up to 50,000 cycles depending on voltage/endurance
Mounting Mode Fixed, bolt‑on, backplate support
Connection Pitch 35 mm
Control Type Toggle or rotary (front access)
Weight ~2.05 kg (≈5 lb)
Standards / Certifications EN/IEC 60947‑2, UL 508, NEMA AB1, CCC, EAC
IP / IK Rating IP40, IK07
Operating Temp. −25 °C to +70 °C
Storage Temp. −50 °C to +85 °C
Sustainability Green Premium, RoHS/REACh compliant
