LV430680 | SCHNEIDER ELECTRIC | Circuit Breaker Compact NSX160H, 70 kA at 415 VAC, TMD Trip Unit 160 A, 4 Poles 3d
₹ 50,274.95
LV430680 | SCHNEIDER ELECTRIC | Circuit Breaker Compact NSX160H, 70 kA at 415 VAC, TMD Trip Unit 160 A, 4 Poles 3d
está agotado y se enviará tan pronto como vuelva a estar disponible.
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
LV430680 | SCHNEIDER ELECTRIC | Circuit Breaker Compact NSX160H, 70 kA at 415 VAC, TMD Trip Unit 160 A, 4 Poles 3d
LV430680 | SCHNEIDER ELECTRIC | Circuit Breaker Compact NSX160H, 70...
LV430680 | SCHNEIDER ELECTRIC | Circuit Breaker Compact NSX160H, 70 kA at 415 VAC, TMD Trip Unit 160 A, 4 Poles 3d
está agotado y se enviará tan pronto como vuelva a estar disponible.
Manufacturer Part Number (MPN)
LV430680
Original Equipment Manufacturer
SCHNEIDER ELECTRIC
Descripción
Manufacturer
Schneider Electric – ComPact NSX series (NSX160H)
Device Type
Fixed MCCB (Molded Case Circuit Breaker)
Rated Current (In)
160 A @ 40 °C
Poles
4P (3t + neutral, left neutral position)
Rated Operational Voltage (Ue)
690 VAC, 50/60 Hz
Trip Unit
Thermal‑Magnetic TM‑D fixed
Utilisation Category
Category A per IEC 60947‑2
Rated Insulation Voltage (Ui)
800 VAC
Impulse Withstand Voltage (Uimp)
8 kV
Ultimate Breaking Capacity (Icu)
70 kA @ 380–415 VAC; 10 kA @ 660–690 VAC; 100 kA @ 220–240 VAC; 35 kA @ 525 VAC; 50 kA @ 500 VAC; 65 kA @ 440 VAC
Service Breaking Capacity (Ics)
Same values as Icu per IEC 60947‑2
Mechanical Durability
40,000 cycles
Electrical Durability
20,000 @ 440 VAC; 7,500 @ 690 VAC (In/2)
Operating Temperature Range
−25 °C to +70 °C
Mounting
Fixed backplate; front connection terminals
Connection Pitch
35 mm
Dimensions (H×W×D)
161 × 140 × 86 mm
Weight
≈ 2.6 kg
Protection Rating
IP40; IK07
Standards & Certifications
IEC 60947‑2, UL 508, CSA, CCC, EAC; marine certs
Overvoltage Category
Class II
Pollution Degree
Degree 3 (IEC 60664‑1)
