SPARECRUX is NOT an authorized distributor for NTN

SM-UCFC206 | NTN | Cast Iron Round Flanged With Spigot Joint

₹ 2,832.40

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

SM-UCFC206

Original Equipment Manufacturer

NTN

Descripción

Specification Details
Unit Type Bearing Unit
Bearing Unit Type Round Flange Shape
Shaft Bore Diameter (d) 30 mm
Unit Body Material Cast Iron
Bearing Inner Diameter Shape Cylindrical Bore Set Screw
Rolling Element Material Steel
Surface Treatment No
Basic Load Rating: Dynamic Load 19,500 N
Basic Load Rating: Static Load 11,300 N
Specifications / Environment -
Cover Type Steel Plate Single Closing Cover
Seal No
Lubrication Method Oil-Free Type
Temperature Properties Standard
Heat Resistant Characteristics -
Basic Dynamic Load Rating Cr 19,500 N
Set Screws Set screw with ball
