ZB4 BK1233 | SCHNEIDER ELECTRIC | Green Illuminated Selector Switch Head, 22mm, 2-Position, Stay-put, Harmony XB4 Series

₹ 2,999.28

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

ZB4 BK1233

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Descripción

Range Harmony XB4
Product or component type Illuminated selector switch head
Device short name ZB4 BK1233
Handle colour Green
Positions 2 positions, 90°
Operation type Stay‑put (maintained)
Bezel material Chromium plated metal
Lens/illumination Universal LED
Cut-out diameter 22 mm
Protection rating IP66, IP67, IP69, IP69K; NEMA 13/4X
Mechanical durability 1,000,000 cycles
Vibration resistance 5 gn (2–500 Hz)
Shock resistance 30 gn / 50 gn
Ambient operating temp. −40…+70 °C
Weight ≈ 0.036 kg
Standards & Certifications EN/IEC 60947‑5‑1/‑5‑4/‑5‑5; UL 508; CSA C22.2; JIS C 4520; GL; DNV; RINA; LROS
Environmental status Green Premium; RoHS/REACh compliant
SCHNEIDER ELECTRIC

ZB4 BK1233 | SCHNEIDER ELECTRIC | Green Illuminated Selector Switch Head, 22mm, 2-Position, Stay-put, Harmony XB4 Series

₹ 2,999.28
Range Harmony XB4
Product or component type Illuminated selector switch head
Device short name ZB4 BK1233
Handle colour Green
Positions 2 positions, 90°
Operation type Stay‑put (maintained)
Bezel material Chromium plated metal
Lens/illumination Universal LED
Cut-out diameter 22 mm
Protection rating IP66, IP67, IP69, IP69K; NEMA 13/4X
Mechanical durability 1,000,000 cycles
Vibration resistance 5 gn (2–500 Hz)
Shock resistance 30 gn / 50 gn
Ambient operating temp. −40…+70 °C
Weight ≈ 0.036 kg
Standards & Certifications EN/IEC 60947‑5‑1/‑5‑4/‑5‑5; UL 508; CSA C22.2; JIS C 4520; GL; DNV; RINA; LROS
Environmental status Green Premium; RoHS/REACh compliant
