6068441 | SICK SENSORS | UM18-21112E211 Ultrasonic Distance Sensor

₹ 37,625.40

À venir!

Nous sommes tellement impatients de découvrir nos prochaines sorties que nous ne pouvions plus les cacher ! Laissez-nous votre adresse e-mail ci-dessous et nous vous préviendrons dès leur sortie :)




Video

Add text to a video to showcase a detail of your brand or product line.

Description

Operating range, limiting range 30 mm ... 250 mm, 350 mm
Target Natural objects
Resolution ≥ 0.069 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2) 3)
Temperature compensation
Response time 32 ms
Switching frequency 25 Hz
Output time 8 ms
Dimensions (W x H x D) 18 mm x 18 mm x 52.7 mm
Design Cylindrical
Sending axis Straight
Housing material Metal (nickel-plated brass, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 25 g
Thread size M18 x 1
Connection type Male connector, M12, 5-pin
