SPARECRUX is NOT an authorized distributor for SICK SENSORS

1103993 | SICK SENSORS | IHM03-1B5NSVU2S Inductive Proximity Sensor

₹ 5,834.40

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1103993

Original Equipment Manufacturer

SICK SENSORS

説明

Housing Cylindrical
Housing Standard design
Diameter Ø 3 mm
Sensing range Sn 1.5 mm
Safe sensing range Sa 1.215 mm
Installation type Quasi-flush
Switching frequency 4,400 Hz
Connection type Cable, 3-wire, 2 m
Switching output NPN
Switching output detail NPN
Supply voltage 10 V DC ... 30 V DC
Ripple ≤ 20 % 1)
Voltage drop ≤ 2 V 2)
Time delay before availability ≤ 30 ms
Hysteresis 1 % ... 20 %
Reproducibility ≤ 2.5 % 3)
Temperature drift (of Sr) ≤ 10 %
EMC EN 60947-5-2
Continuous current Ia ≤ 100 mA
Cable material PUR
SICK SENSORS

1103993 | SICK SENSORS | IHM03-1B5NSVU2S Inductive Proximity Sensor

₹ 5,834.40
Housing Cylindrical
Housing Standard design
Diameter Ø 3 mm
Sensing range Sn 1.5 mm
Safe sensing range Sa 1.215 mm
Installation type Quasi-flush
Switching frequency 4,400 Hz
Connection type Cable, 3-wire, 2 m
Switching output NPN
Switching output detail NPN
Supply voltage 10 V DC ... 30 V DC
Ripple ≤ 20 % 1)
Voltage drop ≤ 2 V 2)
Time delay before availability ≤ 30 ms
Hysteresis 1 % ... 20 %
Reproducibility ≤ 2.5 % 3)
Temperature drift (of Sr) ≤ 10 %
EMC EN 60947-5-2
Continuous current Ia ≤ 100 mA
Cable material PUR
