11911 | FESTO | Semi-rotary Drive DSR-25-180-P

₹ 18,301.48

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

11911

Original Equipment Manufacturer

FESTO

説明

Property Specification
Size 25
Cushioning angle 1.8°
Rotation angle adjustment range 0° ... 180°
Swivel angle 0° ... 180°
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Design Vane
Position detection Without
Symbol 00991265
Operating pressure 1.5 bar ... 8 bar
Max. swivel frequency @ 6 bar 3 Hz
Operating medium Compressed air (ISO 8573-1:2010 [7:-:-])
LABS (PWIS) conformity VDMA24364-B2-L
Ambient temperature -10 °C ... 60 °C
Max. axial force 50 N
Max. radial force 120 N
Theoretical torque @ 6 bar 5 Nm
Product weight 500 g
Type of mounting With through-hole
Pneumatic connection M5
Material covering PA-reinforced
Material drive shaft Nickel-plated steel
Material seals NBR
Material housing Die-cast zinc
