1222210000 | WEIDMULLER | Diode Module

₹ 313.50

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1222210000

Original Equipment Manufacturer

WEIDMULLER

説明
Attribute Details
GTIN (EAN) 4050118005608
Dimensions (L x W x H) 150 mm x 34 mm x 130 mm
Net Weight 584 g
Input Voltage Range 18–30 V DC
Nominal Input Voltage 24 V DC
Input Current 2 x 10 A or 1 x 20 A
Output Voltage 24 V DC ±1%
Continuous Output Current 20 A @ 60°C
Maximum Output Current 24 A @ 45°C, 22.5 A @ 55°C, 15 A @ 70°C
Voltage Drop Input voltage – 0.7 V
Switching Thresholds 21.6 V DC (Power Good), 20.4 V DC (Power Fail)
Operating Temperature Range -25°C to +70°C
Storage Temperature Range -40°C to +85°C
Humidity 5–95%, non-condensing
EMC Compliance EN 61000-4 series, EN 55032 Class B
Shock Resistance IEC 60068-2-27, 15 g in all directions
Vibration Resistance IEC 60068-2-6, 1 g according to EN 50178
Replacement Product 2486090000
