SPARECRUX is NOT an authorized distributor for FESTO

1360248 | FESTO | Semi-rotary Drive DRRD-25-180-FH-Y9A

₹ 46,113.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1360248

Original Equipment Manufacturer

FESTO

説明

Feature Details
Swivel angle 180°
Cushioning Internal hydraulic cushioning normal
Mounting position Optional
Design Rack and pinion
Position detection Via proximity switch
Symbol 00991265
Operating pressure 0.2 MPa ... 1 MPa (2 bar ... 10 bar)
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity VDMA24364 zone III
Ambient temperature -10 °C ... 60 °C
Theoretical torque at 0.6 MPa (6 bar, 87 psi) 5.15 Nm
Permissible mass moment of inertia 0.15 kgm²
Product weight 1358 g
Type of mounting Either: With through-hole, Via female thread
Pneumatic connection M5
Note on materials RoHS-compliant
Material drive shaft Tempered steel
Material cover Wrought aluminium alloy, Anodised
Material seals NBR, TPE-U(PU)
Material housing Smooth anodised
