151671 | FESTO | Proximity Sensor SMEO-1-LED-230-B

₹ 6,419.98

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

151671

Original Equipment Manufacturer

FESTO

説明
Property Value
Design Block design
Conforms to standard EN 60947-5-2
Symbol 00991624
Approval RCM trademark, CE mark, UKCA marking
Compliance EU EMC Directive, EU Low Voltage Directive, EU RoHS Directive, UK instructions for EMC, UK RoHS instructions, UK regulations for electrical equipment
Note on materials RoHS-compliant
Measured variable Position
Measuring principle Magnetic reed
Ambient temperature -20 °C ... 70 °C
Repetition accuracy 0.2 mm
Switching output Contacting, bipolar
Switching element function N/O contact
Switch-on time 0.5 ms
Switch-off time 0.03 ms
Max. switching frequency 500 Hz
Max. output current AC 250 mA
Max. output current DC 120 mA
Max. switching capacity AC 40 VA
Max. switching capacity DC 40 W
Voltage drop ≤4.5 V
Off-state current 0 mA
Short circuit current rating No
Overload protection Not available
Operational voltage range AC 5 V ... 250 V
Operational voltage range DC 5 V ... 200 V
Reverse polarity protection No
Electrical connection 1, connection type Cable
Electrical connection 1, connector system Open end
Electrical connection 1, number of connections/cores 2
Connection outlet orientation In-line
Cable length 2.5 m
Cable sheath colour Grey
Material cable sheath PVC
Type of mounting With accessories
Tightening torque 2.9 Nm
Mounting position Optional
Product weight 100 g
Housing colour Black
Material housing PC, PET, Steel, TPE-O, Die-cast zinc
Switching status indication Yellow LED
Ambient temperature with moving cable -5 °C ... 70 °C
Degree of protection IP67
Immunity to surge 4 kV
