162810 | FESTO | On/off Valve HE-1/2-D-MIDI

₹ 3,783.79

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

162810

Original Equipment Manufacturer

FESTO

説明

Parameter Specification
Design Piston gate valve
Type of actuation Manual
Sealing principle Soft
Exhaust-air function Without flow control option
Manual override None
Symbol 00995571
Valve function 3/2 bistable
Operating pressure 0 MPa ... 1.6 MPa
Operating pressure 0 bar ... 16 bar
C value 17 l/sbar
b value 0.3
Standard nominal flow rate (DIN 1343) 3600 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4], Inert gases
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
Note on materials RoHS-compliant
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Type of mounting With accessories
Mounting position Optional
Flow direction Non-reversible
Product weight 511 g
Pneumatic connection, port 1 G1/2
Pneumatic connection, port 2 G1/2
Pneumatic connection, port 3 G1/4
Air purity class at output Compressed air to ISO 8573-1:2010 [7:4:4], Inert gases
Material seals NBR
Material housing Die-cast aluminium
