163400 | FESTO | ISO Cylinder DNC-63- -PPV-A

₹ 7,064.68

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

163400

Original Equipment Manufacturer

FESTO

説明
Property Value
Stroke 3 mm ... 2000 mm
Piston Diameter 63 mm
Piston Rod Thread M16x1.5
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting Position Optional
Conforms to Standard ISO 15552
Piston-Rod End Male thread
Design Piston, Piston rod, Profile barrel
Position Detection Via proximity switch
Symbol 00991235
Variants Piston rod at one end
Operating Pressure 0.06 MPa ... 1.2 MPa0.6 bar ... 12 bar
Mode of Operation Double-acting
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on Operating & Pilot Medium Lubricated operation possible (lubrication always required)
Corrosion Resistance Class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Ambient Temperature -20 °C ... 80 °C
Impact Energy in End Positions 0.5 J
Cushioning Length 22 mm
Theoretical Force at 0.6 MPa (Return Stroke) 1682 N
Theoretical Force at 0.6 MPa (Advance Stroke) 1870 N
Moving Mass for 0 mm Stroke 663 g
Additional Moving Mass per 10 mm Stroke 25 g
Basic Weight for 0 mm Stroke 1709 g
Additional Weight per 10 mm Stroke 73 g
Type of Mounting Via female thread
With Accessories Pneumatic connection G3/8
RoHS Compliance Yes
Material Cover Die-cast aluminium, Coated
Material Seals TPE-U (PU)
Material Piston Rod High-alloy steel
Material Cylinder Barrel Wrought aluminium alloy, Smooth anodised
