SPARECRUX is NOT an authorized distributor for WAGO

2004-1401 | WAGO | "4-conductor Terminal Block, 4 mm², Ex e II, Push-in CAGE CLAMP®, Gray, DIN-rail"

₹ 375.98

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

2004-1401

Original Equipment Manufacturer

WAGO

説明
ATEX Rating PTB 05 ATEX 1095 U
IECEx Rating PTB 05.0033U (Ex eb IIC Gb)
Rated Voltage (Ex e II) 550 V
Rated Current (Ex e II) 30 A
Width 6.2 mm / 0.244 in
Height 78.7 mm / 3.098 in
Depth from Upper Edge of DIN-rail 32.9 mm / 1.295 in
Total Depth 39.5 mm / 1.555 in
Mounting Type DIN-35 rail
Marking Level Center/Side marking
Color Gray
Material Group I
Insulation Material Polyamide (PA66)
Flammability Class (UL94) V0
Fire Load 0.196 MJ
Weight 10.5 g
WAGO

2004-1401 | WAGO | "4-conductor Terminal Block, 4 mm², Ex e II, Push-in CAGE CLAMP®, Gray, DIN-rail"

₹ 375.98
ATEX Rating PTB 05 ATEX 1095 U
IECEx Rating PTB 05.0033U (Ex eb IIC Gb)
Rated Voltage (Ex e II) 550 V
Rated Current (Ex e II) 30 A
Width 6.2 mm / 0.244 in
Height 78.7 mm / 3.098 in
Depth from Upper Edge of DIN-rail 32.9 mm / 1.295 in
Total Depth 39.5 mm / 1.555 in
Mounting Type DIN-35 rail
Marking Level Center/Side marking
Color Gray
Material Group I
Insulation Material Polyamide (PA66)
Flammability Class (UL94) V0
Fire Load 0.196 MJ
Weight 10.5 g
