SPARECRUX is NOT an authorized distributor for WAGO

280-901 | WAGO | 2-conductor Through Terminal Block; 2.5 mm², Center Marking, For DIN-rail 35 x 15 and 35 x 7.5, CAGE CLAMP®, 2,50 mm², Gray

₹ 379.92

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

280-901

Original Equipment Manufacturer

WAGO

説明

Power Loss, per Pole (Potential) 0.766 W
Rated Current IN for Power Loss Specification 24 A
Resistance Value (Current-Dependent Power Loss) 0.001 Ω
Width 5 mm / 0.197 inches
Height 53 mm / 2.087 inches
Depth from Upper-Edge of DIN-Rail 28 mm / 1.102 inches
Mounting Type DIN-35 rail
Marking Level Center marking
Color Gray
Material Group I
Insulation Material (Main Housing) Polyamide (PA66)
Flammability Class per UL94 V0
Fire Load 0.096 MJ
Weight 5.4 g
WAGO

280-901 | WAGO | 2-conductor Through Terminal Block; 2.5 mm², Center Marking, For DIN-rail 35 x 15 and 35 x 7.5, CAGE CLAMP®, 2,50 mm², Gray

₹ 379.92
Power Loss, per Pole (Potential) 0.766 W
Rated Current IN for Power Loss Specification 24 A
Resistance Value (Current-Dependent Power Loss) 0.001 Ω
Width 5 mm / 0.197 inches
Height 53 mm / 2.087 inches
Depth from Upper-Edge of DIN-Rail 28 mm / 1.102 inches
Mounting Type DIN-35 rail
Marking Level Center marking
Color Gray
Material Group I
Insulation Material (Main Housing) Polyamide (PA66)
Flammability Class per UL94 V0
Fire Load 0.096 MJ
Weight 5.4 g
