284-107 | WAGO | 2‑Conductor Ground Terminal Block, 10 mm², Green‑Yellow, CAGE CLAMP®

₹ 944.42

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

284-107

Original Equipment Manufacturer

WAGO

説明
Property Value
Connection technology CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Solid conductor 0.2 … 10 mm² / 24 … 8 AWG
Fine-stranded conductor 0.2 … 10 mm² / 24 … 8 AWG
Strip length 12 … 13 mm / 0.47 … 0.51 inches
Wiring direction Side-entry wiring
Width 10 mm / 0.394 inches
Height 52 mm / 2.047 inches
Depth from upper-edge of DIN-rail 41.5 mm / 1.634 inches
Design horizontal type
Mounting type DIN-35 rail
Marking level Side marking
Color green-yellow
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class per UL94 V0
Fire load 0.266MJ
Weight 27.1g
