285-607 | WAGO | 2-conductor Ground Terminal Block, 35 mm²DIN 35 x 15 Rail, CAGE CLAMP®, 35,00 mm², Green-yellow

₹ 3,145.45

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

285-607

Original Equipment Manufacturer

WAGO

説明

Property Specification
Connectable Conductor Materials Copper
Nominal Cross-Section 35 mm²
Solid Conductor 6 … 35 mm² / 8 … 2 AWG
Width 16 mm / 0.63 inches
Height 115.5 mm / 4.547 inches
Depth from Upper-Edge of DIN-Rail 52.5 mm / 2.067 inches
Design Horizontal type
Mounting Type DIN-35 rail
Mounting (Note) Only suitable for DIN 35 x 15 rail
Marking Level Side marking
Color Green-yellow
Material Group I
Insulation Material (Main Housing) Polyamide (PA66)
Flammability Class per UL94 V0
Fire Load 1.165 MJ
Weight 152.3 g
