532649 | FESTO | Vacuum Generator VN-14-L-T4-PQ3-VQ3-RO2-B

₹ 7,064.49

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

532649

Original Equipment Manufacturer

FESTO

説明

Property Value
Nominal size, Laval nozzle 1.4 mm
Grid dimension 18 mm
Silencer design Open
Mounting position Optional
Ejector characteristic Standard
High suction volume Yes
Manual override Non-detenting
Integrated function Ejector pulse valve, pneumatic; Electric on-off valve; Open silencer
Design T-shape
Symbol 00991944
Valve function 2/2
Operating pressure for max. suction flow rate 5 bar
Operating pressure 2 bar ... 8 bar
Nominal operating pressure 6 bar
Max. suction flow rate against atmosphere 92.6 l/min
Air supply time at nominal operating pressure 0.32 s
Operational voltage range DC 21.6 V ... 26.4 V
Electrical power consumption 1.2 W
Duty cycle 100%
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation not possible
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364 zone III
Media temperature 0 °C ... 50 °C
Sound pressure level at nominal operating pressure 69 dB(A)
Degree of protection IP40
Ambient temperature 0 °C ... 50 °C
Product weight 100 g
Electrical connection Plugs
Type of mounting With through-hole; With H-rail; With accessories
Pneumatic connection, port 1 QS-8
Pneumatic connection, port 3 Open silencer
Vacuum connection QS-8
Material connecting thread Anodised wrought aluminium alloy
Note on materials RoHS-compliant
Material seals NBR
Material receiver nozzle POM
Material housing POM-reinforced
Material silencer Wrought aluminium alloy; POM; PU foam
Material screws Steel
Material transmitter nozzle Wrought aluminium alloy
Material fitting Brass, Nickel-plated
