575418 | FESTO | Connecting Cable NEBV-S1G25-K-5-N-LE25-S6

₹ 4,545.91

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

575418

Original Equipment Manufacturer

FESTO

説明
Specification Details
Based on standard DIN 47100
Cable designation Without inscription label holder
Frequency of connection 50
Product weight 930 g
Electrical connection 1, function Field device side
Electrical connection 1, design Angular
Electrical connection 1, connection type Socket
Electrical connection 1, cable outlet Straight
Electrical connection 1, connector system Sub-D
Electrical connection 1, number of connections/cores 25
Electrical connection 1, used connections/cores 25
Electrical connection 1, type of mounting 2x screw 4-40 UNC
Electrical connection 1, connection pattern 00995642
Electrical connection 2, function Controller side
Electrical connection 2, connection type Cable
Electrical connection 2, connector system Open end
Electrical connection 2, number of connections/cores 25
Electrical connection 2, used connections/cores 25
Operational voltage range DC 0 V ... 30 V
Current rating at 40° C 2.6 A
Immunity to surge 2.4 kV
Reverse polarity protection yes
Cable length 5 m
Cable characteristic Standard
Test conditions cable Test conditions on request
Bending radius, fixed cable ≥42 mm
Bending radius, moving cable ≥126 mm
Cable diameter 10.2 mm
Cable diameter tolerance ± 0.25 mm
Cable structure 25 x 0.34 mm²
Nominal cross section conductor 0.34 mm²
Wire ends Cut off bluntly
Degree of protection IP40
Note on degree of protection In assembled state
Ambient temperature -35 °C ... 80 °C
Ambient temperature with moving cable -5 °C ... 80 °C
Storage temperature -25 °C ... 75 °C
CE mark (see declaration of conformity) In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity) To UK RoHS instructions
LABS (PWIS) conformity VDMA24364-B2-L
Note on materials RoHS-compliant
Pollution degree 2
Corrosion resistance class CRC 0 - No corrosion stress
Material cable sheath PVC
Cable sheath colour Grey
Material housing PC-reinforced
Housing colour Black
Material screws Nickel-plated brass
