6030706 | SICK SENSORS | WT100L-E2141 Photoelectric Proximity Sensor

₹ 15,473.70
Get Best Price on WhatsApp

Product Description
Specification Details
Functional principle Photoelectric proximity sensor
Functional principle detail Energetic
Dimensions (W x H x D) 11 mm x 31 mm x 20 mm
Housing design (light emission) Rectangular
Sensing range max. 0 mm … 450 mm¹
Sensing range 0 mm … 400 mm
Type of light Visible red light
Light source Laser²
Supply voltage UB 10 V DC … 30 V DC¹
Ripple ± 10 %²
Current consumption 30 mA³
Switching output NPN
Switching mode Light/dark switching



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

6030706

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle – Photoelectric proximity sensor

Functional principle detail – Energetic

Dimensions (W x H x D) – 11 mm x 31 mm x 20 mm

Housing design (light emission) – Rectangular

Sensing range max. – 0 mm ... 450 mm 1)

Sensing range – 0 mm ... 400 mm

Type of light – Visible red light

Light source – Laser 2)

Light spot size (distance) – Ø 2 mm (400 mm)

Wave length – 650 nm

Laser class – 1 3)

Adjustment – Potentiometer, 270°

Special applications – Detecting small objects, Detection of objects moving at high speeds

Supply voltage UB – 10 V DC ... 30 V DC 1)

Ripple – ± 10 % 2)

Current consumption – 30 mA 3)

Switching output – NPN

Switching mode – Light/dark switching

Switching mode selector – Selectable via light/dark rotary switch

Signal voltage NPN HIGH/LOW – Approx. VS / < 1.8 V

Output current Imax. – ≤ 100 mA

Response time – < 0.25 ms 4)

Switching frequency – 2,000 Hz 5)

Connection type – Connector M8, 3-pin

MTTFD – 453 years

DCavg – 0 %

EU declaration of conformity – ✔

UK declaration of conformity – ✔

ACMA declaration of conformity – ✔

Moroccan declaration of conformity – ✔

China RoHS – ✔

cRUus certificate – ✔

Laser safety (IEC 60825-1) certificate – ✔

ECLASS 5.0 – 27270903

ECLASS 5.1.4 – 27270903

ECLASS 6.0 – 27270903

ECLASS 6.2 – 27270903

ECLASS 7.0 – 27270903

ECLASS 8.0 – 27270903

ECLASS 8.1 – 27270903

ECLASS 9.0 – 27270903
