A9K24110 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker Acti9 IK60N 1P 10A C curve 6000A

₹ 342.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

A9K24110

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

説明
Series / Range Acti9 iK60 (Acti9 iK60N)
Type Miniature Circuit Breaker (MCB), thermal‑magnetic trip
Poles 1 Pole (1P) – Single pole
Rated Current (In) 10 A @ 30 °C
Network Type AC, 50/60 Hz
Trip Curve C‑Curve (5…10 × In magnetic trip)
Breaking Capacity (Icn/Ics) 6000 A @ 230 VAC (100 % Ics)
Rated Operational Voltage (Ue) 230 VAC @ 50/60 Hz
Rated Insulation Voltage (Ui) 440 VAC
Impulse Withstand Voltage (Uimp) 4 kV
Control / Handle Type Toggle switch with ON/OFF indication
Isolation Capability Yes (per EN/IEC 60898‑1)
Durability (Mechanical) 20,000 operations
Durability (Electrical) 10,000 operations
Mounting Mode Clip‑on on 35 mm DIN rail or screw‑mounted panel
Connection Pitch / Width 18 mm width (2 × 9 mm modules)
Terminal Type Tunnel terminals (top or bottom), rigid 1–25 mm² or flexible 1–16 mm²
Wire Stripping Length 14 mm
Tightening Torque 2 N·m (top or bottom terminals)
Locking Feature Padlocking possible
Weight Approx. 100 g
Color White
Protection Rating IP20 (IEC 60529)
Pollution Degree 2 (IEC/EN 60898‑1)
Overvoltage Category III
Operating Temperature −25 °C to +60 °C
Storage Temperature −40 °C to +85 °C
Standards & Certifications EN/IEC 60898‑1; Green Premium, RoHS & REACh compliant
Environmental Footprint Approximately 2 kg CO₂-eq per product lifecycle
