CA2KN40M7 | SCHNEIDER ELECTRIC | TeSys K Control Relay - 4 NO - <= 690 V - 220...230 V AC Coil

₹ 1,600.75

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CA2KN40M7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

説明
Manufacturer Schneider Electric (TeSys K series)
Device Type IEC Control Relay, 4 NO (4‑PST‑NO)
Coil Voltage 220–230 V AC, 50/60 Hz
Rated Load Voltage ≤ 690 V AC
Rated Current (Ith) 10 A at ≤50 °C (AC‑15 / DC‑13)
Contact Configuration 4 NO (single-throw normally open)
Making Capacity (Irms) Up to 110 A (IEC 60947‑1)
Coefficient Ratings A600 / Q600 ratings 10 A (UL/CSA)
Coil Power Inrush ~30 VA, sealed ~4.5 VA :contentReference[oaicite:1]{index=1}
Mounting DIN‑rail clip or panel (4 mm screw) :contentReference[oaicite:2]{index=2}
Terminal Type Screw clamp, torque ~0.8 Nm, wire size #12–#18 AWG :contentReference[oaicite:3]{index=3}
Operating Time Approx. 20 ms (energise/release) :contentReference[oaicite:4]{index=4}
Operating Temperature −25 °C to +50 °C; Storage −40 °C to +85 °C :contentReference[oaicite:5]{index=5}
Weight ~0.18 kg (0.40 lb) :contentReference[oaicite:6]{index=6}
Standards & Certifications IEC 60947, UL 508, CSA (UL File E164353 / CSA LR43364) :contentReference[oaicite:7]{index=7}
IP Rating IP20 (terminals) :contentReference[oaicite:8]{index=8}
