KL5001 | BECKHOFF | Bus Terminal, 1-channel Encoder Interface, SSI

₹ 16,937.34

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KL5001

Original Equipment Manufacturer

BECKHOFF

説明
Technology SSI encoder interface
Number of channels 1 encoder interface
Encoder connection binary input: D+, D-, binary output: Cl+, Cl-
Power supply 24 V DC via power contacts
Current consumption typ. 20 mA without encoder
Current consumption power contacts typ. 20 mA + load
Encoder supply 24 V DC via power contacts
Data transfer rates variable up to 1 MHz, 250 kHz default
Serial input 24 bit width (variable)
Data direction read
Signal output difference signal (RS422)
Signal input difference signal (RS422)
Electrical isolation 500 V (K-bus/field potential)
Current consumption K-bus typ. 25 mA
BECKHOFF

KL5001 | BECKHOFF | Bus Terminal, 1-channel Encoder Interface, SSI

₹ 16,937.34
Technology SSI encoder interface
Number of channels 1 encoder interface
Encoder connection binary input: D+, D-, binary output: Cl+, Cl-
Power supply 24 V DC via power contacts
Current consumption typ. 20 mA without encoder
Current consumption power contacts typ. 20 mA + load
Encoder supply 24 V DC via power contacts
Data transfer rates variable up to 1 MHz, 250 kHz default
Serial input 24 bit width (variable)
Data direction read
Signal output difference signal (RS422)
Signal input difference signal (RS422)
Electrical isolation 500 V (K-bus/field potential)
Current consumption K-bus typ. 25 mA
