SPARECRUX is NOT an authorized distributor for SCHRACK

RT33L024 | SCHRACK | Relay 16A 24VDC

₹ 314.91

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

RT33L024

Original Equipment Manufacturer

SCHRACK

説明

Parameter Details
Manufacturer TE Connectivity / Schrack (RT1 Series)
Part Number RT33L024
Contact Configuration SPST-NO (Single Pole Single Throw, Normally Open)
Coil Voltage 24 V DC
Contact Current 16 A
Contact Voltage 250 VAC
Coil Resistance 1.44 kΩ
Coil Type Non-latching (Monostable)
Mounting Through-hole (PCB)
Contact Material Silver Tin Oxide (AgSnO₂)
Inrush Current Up to 80 A
Dielectric Strength 5 kV between coil and contacts
Ambient Temperature –40°C to +85°C
Environmental Rating RT II (Reinforced insulation)
SCHRACK

RT33L024 | SCHRACK | Relay 16A 24VDC

₹ 314.91
Parameter Details
Manufacturer TE Connectivity / Schrack (RT1 Series)
Part Number RT33L024
Contact Configuration SPST-NO (Single Pole Single Throw, Normally Open)
Coil Voltage 24 V DC
Contact Current 16 A
Contact Voltage 250 VAC
Coil Resistance 1.44 kΩ
Coil Type Non-latching (Monostable)
Mounting Through-hole (PCB)
Contact Material Silver Tin Oxide (AgSnO₂)
Inrush Current Up to 80 A
Dielectric Strength 5 kV between coil and contacts
Ambient Temperature –40°C to +85°C
Environmental Rating RT II (Reinforced insulation)
