060B016766 | DANFOSS | Differential Pressure Switch, MP54

₹ 30,730.90

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

060B016766

Original Equipment Manufacturer

DANFOSS

Description

Specification Details
Model 060B016766
Type Differential Pressure Switch (MP54)
Reset Function Manual Minimum
Pressure Connection Type Flare
Pressure Connection Size 1/4 inch
Enclosure Rating IP20
Max. Working Pressure 17.0 bar (245 psi)
Max. Test Pressure 22.0 bar (319 psi)
Ambient Temperature Range -40°C to +60°C
Contact Differential 0.20 bar
Fixed Differential 0.90 bar
Contact Function SPDT (Single Pole Double Throw)
Contact Rating AC15 = 2 A, 250 V; DC13 = 0.2 A, 250 V
Electrical Connection Female, screwed cable entry (Pg 13.5)
Electrical Standard EN 60947-5
Relay Release Time 60 seconds
Refrigerant Compatibility R11, R12, R22, R134a, R404A, R407A, R507, and others
Approvals CE, UL, CCC, RoHS, EAC, DNV GL, and more
Weight 0.65 kg (net), 0.757 kg (gross)
Packing Format Multi-pack (21 units per pack)
