SPARECRUX is NOT an authorized distributor for EUCHNER

084885 | EUCHNER | Safety Switch Nz.Vz, Plug Connector Sr6

₹ 24,247.56

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

084885

Original Equipment Manufacturer

EUCHNER

Description
Switching Elements 1 NC (Normally Closed) contact, 1 NO (Normally Open) contact
Actuating Force 35 N
Actuation Frequency Max. 1200 operations per hour
Approach Speed Max. 20 m/min
Approach Direction Horizontal (can be adjusted in 90° steps)
Degree of Protection IP67
Rated Insulation Voltage 250 V AC/DC
Rated Impulse Withstand Voltage 2.5 kV
Utilization Category AC-15: 4 A at 230 V
DC-13: 4 A at 24 V
Short Circuit Protection 4 A gG (according to IEC 60269-1)
Switching Current Minimum 1 mA at 24 V
Switching Voltage Minimum 12 V at 10 mA
Thermal Rated Current 4 A
Ambient Temperature Range -25°C to +80°C
Housing Die-cast alloy
EUCHNER

084885 | EUCHNER | Safety Switch Nz.Vz, Plug Connector Sr6

₹ 24,247.56
Switching Elements 1 NC (Normally Closed) contact, 1 NO (Normally Open) contact
Actuating Force 35 N
Actuation Frequency Max. 1200 operations per hour
Approach Speed Max. 20 m/min
Approach Direction Horizontal (can be adjusted in 90° steps)
Degree of Protection IP67
Rated Insulation Voltage 250 V AC/DC
Rated Impulse Withstand Voltage 2.5 kV
Utilization Category AC-15: 4 A at 230 V
DC-13: 4 A at 24 V
Short Circuit Protection 4 A gG (according to IEC 60269-1)
Switching Current Minimum 1 mA at 24 V
Switching Voltage Minimum 12 V at 10 mA
Thermal Rated Current 4 A
Ambient Temperature Range -25°C to +80°C
Housing Die-cast alloy
