SPARECRUX is NOT an authorized distributor for WEIDMULLER

1036180000 | WEIDMULLER | Feed-through terminal Block Screw Connection

₹ 147.20

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1036180000

Original Equipment Manufacturer

WEIDMULLER

Description
Type WDU 16N BL
GTIN (EAN) 4008190273224
Depth 46.5 mm
Depth (inches) 1.831 inch
Depth including DIN rail 47 mm
Height 60 mm
Height (inches) 2.362 inch
Width 12 mm
Width (inches) 0.472 inch
Net weight 24.06 g
Storage temperature -25 °C...55 °C
Ambient temperature -5 °C…40 °C
Continuous operating temp., min. -50 °C
Continuous operating temp., max. 120 °C
RoHS Compliance Status Compliant without exemption
REACH SVHC No SVHC above 0.1 wt%
Product Carbon Footprint (Cradle to gate) 0.413 kg CO2eq.
Basic material Wemid
Colour blue
WEIDMULLER

1036180000 | WEIDMULLER | Feed-through terminal Block Screw Connection

₹ 147.20
Type WDU 16N BL
GTIN (EAN) 4008190273224
Depth 46.5 mm
Depth (inches) 1.831 inch
Depth including DIN rail 47 mm
Height 60 mm
Height (inches) 2.362 inch
Width 12 mm
Width (inches) 0.472 inch
Net weight 24.06 g
Storage temperature -25 °C...55 °C
Ambient temperature -5 °C…40 °C
Continuous operating temp., min. -50 °C
Continuous operating temp., max. 120 °C
RoHS Compliance Status Compliant without exemption
REACH SVHC No SVHC above 0.1 wt%
Product Carbon Footprint (Cradle to gate) 0.413 kg CO2eq.
Basic material Wemid
Colour blue
