SPARECRUX is NOT an authorized distributor for SICK SENSORS

1047314 | SICK SENSORS | DT50-P2113 Laser Distance Sensor

₹ 87,629.60

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1047314

Original Equipment Manufacturer

SICK SENSORS

Description
Target Natural objects
Resolution 1 mm
Repeatability ≥ 1 mm 1) 2) 3)
Measurement accuracy ± 7 mm 4)
Response time 15 ms ... 80 ms, 15 ms / 30 ms / 80 ms 3) 5)
Output time ≥ 2 ms 6)
Light source Laser, red
visible red light
Type of light Visible red light
Laser class 2 (IEC 60825-1:2014, EN 60825-1:2014) 7)
Supply voltage UB DC 10 V ... 30 V 1)
Power consumption ≤ 2.1 W 2)
Ripple ≤ 5 Vpp 3)
Initialization time ≤ 250 ms
Warm-up time ≤ 15 min
Indication LC display, 2 x LED
Enclosure rating IP65



SICK SENSORS 1047314 DT50-P2113 Laser Distance Sensor
