1058987 | SICK SENSORS | DL50-N2228 Laser Distance Sensor

₹ 75,996.80

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1058987

Original Equipment Manufacturer

SICK SENSORS

Description
Measuring range 200 mm ... 50,000 mm, on “diamond grade” reflective tape
Target Reflector
Resolution 0.1 mm
Repeatability ≥ 0.25 mm 1) 2) 3)
Measurement accuracy ± 3 mm 4)
Response time 10 ms ... 160 ms, 10 ms / 40 ms / 160 ms 2) 5)
Output time 2.5 ms 6)
Light source Laser, red
visible red light
Type of light Visible red light
Supply voltage UB DC 10 V ... 30 V 1)
Power consumption ≤ 2.1 W 2)
Ripple ≤ 5 Vpp 3)
Initialization time ≤ 250 ms
Warm-up time ≤ 15 min
Indication LC display, 2 x LED
Enclosure rating IP65
