1059442 | SICK SENSORS | MPA-107THTP0 Cylinder Sensors

₹ 25,284.80

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1059442

Original Equipment Manufacturer

SICK SENSORS

Description
Measuring range 107 mm 1)
Housing length 109 mm
Output function Analog, IO-Link
Electrical wiring DC 4-wire
Analog output (voltage) 0 V ... 10 V
Analog output (current) 4 mA ... 20 mA 2)
Supply voltage 15 V DC ... 30 V DC
Power consumption 35 mA, without load
Max. load resistance ≤ 500 Ω Power Output, at 24 V
Min. load resistance ≥ 2 kΩ 1)
Protection class III
Required magnetic field sensitivity, typ. 2 mT ... 15 mT
Resolution, typ.

0.03 % FSR (max. ≥ 0.06 mm) 2)

 3)
Linearity error, typ. 0.5 mm 4)
Repeat accuracy, typ. 0.06 % FSR (≥ 0.1 mm) 5)
Sampling rate, typ. 1.15 ms 6)
Reverse polarity protection Yes
