1072739 | SICK SENSORS | IMB12-08NPOVC0S Inductive Proximity Sensors

₹ 2,862.00

Get Best Price on WhatsApp

Product Description

Housing Metric
Housing Standard design
Thread size M12 x 1
Diameter Ø 12 mm
Sensing range Sn 8 mm
Safe sensing range Sa 6.48 mm
Installation type Non-flush
Switching frequency 2,000 Hz
Connection type Male connector M12, 4-pin 1)
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 65 mm
Thread length 43 mm



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1072739

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet
  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Standard design

Thread size - M12 × 1

Diameter - Ø 12 mm

Sensing range (Sn) - 8 mm

Safe sensing range (Sa) - 6.48 mm

Installation type - Non-flush

Switching frequency - 2,000 Hz

Connection type - Male connector M12, 4-pin

Switching output - PNP

Switching output detail - PNP

Output function - NC

Supply voltage - 10 V DC … 30 V DC

Ripple - ≤ 10 %

Voltage drop - ≤ 2 V

Hysteresis - 3 % … 20 %

Reproducibility - ≤ 2 %

Temperature drift (Sr) - ± 10 %

EMC - According to EN 60947-5-2

Continuous current (Ia) - ≤ 200 mA

No load current - ≤ 10 mA

Short-circuit protection - ✔

MTTFD - 1,971 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

ECLASS 5.1.4 - 27270101

ECLASS 6.0 - 27270101

ECLASS 7.0 - 27270101

ECLASS 8.0 - 27270101

ECLASS 9.0 - 27270101

ECLASS 10.0 - 27270101

ECLASS 11.0 - 27270101
