1111086 | SICK SENSORS | MPS-200CLTQ0 Cylinder Sensors

₹ 39,603.20

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1111086

Original Equipment Manufacturer

SICK SENSORS

Description
Measuring range 200 mm 1)
Housing length 215 mm
Switching output Push-pull: PNP/NPN
Output function Analog, IO-Link
Electrical wiring DC 4-wire
Analog output (voltage) 0 V ... 10 V
Analog output (current) 4 mA ... 20 mA
Supply voltage 12 V DC ... 30 V DC
Power consumption 42 mA, without load
Voltage drop ≤ 2 V
Continuous current Ia ≤ 100 mA 1)
Max. load resistance ≤ 500 Ω Power Output, at 24 V
Min. load resistance ≥ 2 kΩ 2)
Protection class III
Time delay before availability 0.15 s
Required magnetic field sensitivity, typ. 3 mT ... 12 mT
Resolution, typ. ≥ 50 µm
Linearity error, typ. 0.3 mm 3)
Repeat accuracy, typ. 0.1 mm 4)
Sampling rate, typ. 1 ms



SICK SENSORS 1111086 MPS-200CLTQ0 Cylinder Sensors
