131B0860 | DANFOSS | Frequency Converter 7.5KW(400V) 10HP(460V) 50/60HZ

₹ 1,866,068.85

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

131B0860

Original Equipment Manufacturer

DANFOSS

Description

Specification Details
Model 131B0860 (FC-302P7K5T5E20H1XGXXXXSXXXXA4BXCXXXXDX)
Power Rating 7.5 kW (10 HP)
Input Voltage 380–500 V AC, 3-phase ±10% at 50–60 Hz
Output Voltage 3-phase variable frequency (VxF control)
Frame Size A3 (268 mm H × 130 mm W × 205 mm D)
Enclosure Rating IP20 (open chassis)
RFI Filter IEC EN61800-3 Class A1/B, Category C1
Brake Chopper Not included
Keypad Not included
Mounting Wall or cubicle mount in clean environment
Ambient Temperature Rating Up to 45°C
DANFOSS

131B0860 | DANFOSS | Frequency Converter 7.5KW(400V) 10HP(460V) 50/60HZ

₹ 1,866,068.85
Specification Details
Model 131B0860 (FC-302P7K5T5E20H1XGXXXXSXXXXA4BXCXXXXDX)
Power Rating 7.5 kW (10 HP)
Input Voltage 380–500 V AC, 3-phase ±10% at 50–60 Hz
Output Voltage 3-phase variable frequency (VxF control)
Frame Size A3 (268 mm H × 130 mm W × 205 mm D)
Enclosure Rating IP20 (open chassis)
RFI Filter IEC EN61800-3 Class A1/B, Category C1
Brake Chopper Not included
Keypad Not included
Mounting Wall or cubicle mount in clean environment
Ambient Temperature Rating Up to 45°C
