SPARECRUX is NOT an authorized distributor for DANFOSS

131L9866 | DANFOSS | VLT® HVAC Drive FC- 101 (P4K0) 4.0 KW / 5.0 HP, Three phase 380 - 480 VAC, (E20) IP20

₹ 32,775.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

131L9866

Original Equipment Manufacturer

DANFOSS

Description

Attribute Details
Model Number 131L9866 / FC-101P4K0T4E20H4XXCXXXSXXXXAXBXCXXXXDX
Product Series VLT® HVAC BasicDrive FC-101
Power Rating 4.0 kW / 5.5 HP
Input Voltage 3-phase: 380–480 V ±10%, 50/60 Hz
Output Current 9 A (at 3-phase 380–480 V)
Output Frequency 0–400 Hz
Enclosure Type IP20 (Chassis)
RFI Filter Class A1 (IEC Category C2)
Brake Chopper Not included
Local Control Panel Not included (optional accessory)
Coating Coated PCB
Frame Size H2
Dimensions (W x H x D) 90 mm x 227 mm x 190 mm
Weight 3.5 kg (net), 3.97 kg (gross)
Volume 16.53 L
Certifications CE, UL/cUL, RoHS; UL LZGH2 compliant (A2L refrigerants)
Typical Applications HVAC fan and blower systems, pumps and compressors in HVAC/R settings, OEM control panel assemblies, BMS integration
