144592 | BALLUFF | BOS 12M-PS-1PD-S4-C Photoelectric Diffuse Sensor

₹ 4,275.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

144592

Original Equipment Manufacturer

BALLUFF

Description

Sensor Type Photoelectric Diffuse Sensor
Housing Material Brass, Nickel-plated
Optical Lens PMMA (Plastic)
Mounting M12 Thread, max. torque 15 Nm
Light Source Infrared LED
Sensing Distance Adjustable 0…400 mm
Output Type PNP, Normally Open (NO)
Connection M12 × 1 Male, 4-pin Connector
Supply Voltage 10–30 V DC
Max. Operating Current 200 mA
No-load Current ≤ 20 mA
Voltage Drop ≤ 2.5 V at Ie
Switching Frequency 200 Hz
Response Time ≤ 2.5 ms
Turn-on Delay ≤ 100 ms
Short Circuit Protection Yes
Polarity Reversal Protection Yes
Ambient Temperature –5 °C to +55 °C
Protection Rating IP67
Adjustment 270° Potentiometer
Indicator LED Yellow – Output State
Compliance CE, cULus, EAC, WEEE
Functional Safety MTTF ~ 831 years
