309EC | SKF | Bearing

₹ 14,754.43

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

309EC

Original Equipment Manufacturer

SKF

Description
Attribute Value
Brand SKF
Model Number NJ 309 ECP
Bore Diameter (d) 45 mm
Outside Diameter (D) 100 mm
Width (B) 25 mm
Number of Rows 1
Design Single row cylindrical roller bearing with integral flanges on both the inner and outer rings
Cage Material Polyamide (non-metallic)
Sealing Open (no seals or shields)
Internal Clearance C3 (greater than normal clearance)
SKF Performance Class SKF Explorer
Basic Dynamic Load Rating (C) 112 kN
Basic Static Load Rating (C₀) 100 kN
Fatigue Load Limit (P₀) 12.9 kN
Reference Speed 7,500 r/min
Limiting Speed 8,500 r/min
Axial Load Factor (Y₀) 0.6
Limiting Value (e) 0.2
Weight 0.89 kg
Country of Origin Germany
