SPARECRUX is NOT an authorized distributor for FAG

3203-BD-XL-TVH-L285 | FAG | Angular Contact Ball Bearing, 17x40x17.5 mm

₹ 1,449.70

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

3203-BD-XL-TVH-L285

Original Equipment Manufacturer

FAG

Description
Brand FAG (Schaeffler Technologies)
Part Number / SKU 3203-BD-XL-TVH-L285
Type Double-row angular contact ball bearing (X-Life)
Inner Diameter (d) 17 mm
Outer Diameter (D) 40 mm
Width (B) 17.50 mm
Weight ~0.096 kg
Bore Type Cylindrical bore
Seal / Shield No seal (open/stainless steel or normal steel rings)
Cage Type TVH moulded polyamide cage
Radial Internal Clearance Normal radial clearance (CN)
Static Load Rating (C₀ᵣ) 9,500 N :contentReference[oaicite:0]{index=0}
Dynamic Load Rating (Cᵣ) 15,500 N :contentReference[oaicite:1]{index=1}
Limiting Speed (nᴳ) 19,400 RPM :contentReference[oaicite:2]{index=2}
Reference Speed (n_ϑᵣ) 16,600 RPM :contentReference[oaicite:3]{index=3}
Contact Angle 30° :contentReference[oaicite:4]{index=4}
Operating Temperature Range -30 °C to +120 °C (grease filled, type L285) :contentReference[oaicite:5]{index=5}
