SPARECRUX is NOT an authorized distributor for SIEMENS

3RT1036-1A..0 | SIEMENS | Contactor

₹ 21,639.58

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

3RT1036-1A..0

Original Equipment Manufacturer

SIEMENS

Description
Specification Details
Brand Siemens (SIRIUS series)
Model Number 3RT1036-1A .. 3RT1036-1A..0
Type 3-phase IEC power contactor
Rated Current AC-3 (400 V) 50 A :contentReference[oaicite:0]{index=0}
Rated Current AC-1 (400 V) 60 A :contentReference[oaicite:1]{index=1}
Horsepower Ratings 15 HP @ 230 V / 40 HP @ 460 V :contentReference[oaicite:2]{index=2}
Number of Poles (Main Circuit) 3 Poles (3 NO contacts) :contentReference[oaicite:3]{index=3}
Control Supply Voltage Multiple versions: e.g. 24V, 110/120V, 220/240V, 440/480V AC etc. :contentReference[oaicite:4]{index=4}
Connection Type Screw terminals :contentReference[oaicite:5]{index=5}
Size / Frame S2 :contentReference[oaicite:6]{index=6}
Mounting Screw + Snap-on onto 35 mm DIN rail :contentReference[oaicite:7]{index=7}
Protection Class (Front) IP20 :contentReference[oaicite:8]{index=8}
Insulation Voltage Rated value 690 V, Surge voltage resistance ~6 kV :contentReference[oaicite:9]{index=9}
Mechanical Life ≈ 10,000,000 switching cycles :contentReference[oaicite:10]{index=10}
Ambient Temperature Range (Operation) -25 °C to +60 °C :contentReference[oaicite:11]{index=11}
Depth × Width × Height ~115 mm × 55 mm × 112 mm :contentReference[oaicite:12]{index=12}
Status Phased-out / discontinued product; successor series is SIRIUS 3RT2. :contentReference[oaicite:13]{index=13}
SIEMENS

3RT1036-1A..0 | SIEMENS | Contactor

₹ 21,639.58
Specification Details
Brand Siemens (SIRIUS series)
Model Number 3RT1036-1A .. 3RT1036-1A..0
Type 3-phase IEC power contactor
Rated Current AC-3 (400 V) 50 A :contentReference[oaicite:0]{index=0}
Rated Current AC-1 (400 V) 60 A :contentReference[oaicite:1]{index=1}
Horsepower Ratings 15 HP @ 230 V / 40 HP @ 460 V :contentReference[oaicite:2]{index=2}
Number of Poles (Main Circuit) 3 Poles (3 NO contacts) :contentReference[oaicite:3]{index=3}
Control Supply Voltage Multiple versions: e.g. 24V, 110/120V, 220/240V, 440/480V AC etc. :contentReference[oaicite:4]{index=4}
Connection Type Screw terminals :contentReference[oaicite:5]{index=5}
Size / Frame S2 :contentReference[oaicite:6]{index=6}
Mounting Screw + Snap-on onto 35 mm DIN rail :contentReference[oaicite:7]{index=7}
Protection Class (Front) IP20 :contentReference[oaicite:8]{index=8}
Insulation Voltage Rated value 690 V, Surge voltage resistance ~6 kV :contentReference[oaicite:9]{index=9}
Mechanical Life ≈ 10,000,000 switching cycles :contentReference[oaicite:10]{index=10}
Ambient Temperature Range (Operation) -25 °C to +60 °C :contentReference[oaicite:11]{index=11}
Depth × Width × Height ~115 mm × 55 mm × 112 mm :contentReference[oaicite:12]{index=12}
Status Phased-out / discontinued product; successor series is SIRIUS 3RT2. :contentReference[oaicite:13]{index=13}
