560362 | FESTO | CPX-4AE-P-D10 Pneumatics Actutor

Name: 560362 | FESTO | CPX-4AE-P-D10 Pneumatics Actutor
Brand: FESTO
Price: 72000.00 INR
Availability: InStock

₹ 72,000.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

560362

Original Equipment Manufacturer

FESTO

Description

Parameter	Specification
Brand	Festo
Model	560362
Type	Analog Input Module
Series	CPX Terminal System
Module Name	CPX-4AE-P-D10
Function	Pressure/analog signal measurement module
Number of Inputs	4
Measured Variables	4× relative pressure / 2× differential pressure
Pressure Range	0 – 10 bar
Operating Voltage	24 V DC (18–30 V DC range)
Power Consumption	~50 mA
Communication	CPX system bus (modular I/O system)
Protection Class	IP65 / IP67
Operating Medium	Compressed air (ISO 8573-1:2010 [7:4:4])
Housing Material	Reinforced PA / PC
Dimensions	50 × 107 × 55 mm
Weight	~115 g
Internal Cycle Time	5 ms
Diagnostics	Channel-wise fault detection, sensor limit monitoring
LABS Compliance	VDMA 24364-B2-L
Corrosion Resistance	CRC 1 (low corrosion stress)
Temperature Range	-5°C to +50°C
Port Connection	QS-4 pneumatic fitting
Application	Industrial automation, pneumatic monitoring, CPX valve terminals
