59402 | MURRELEKTRONIK | MVP12 plastic DI8 DO8 IO-Link I/O module

₹ 31,262.87

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

59402

Original Equipment Manufacturer

MURRELEKTRONIK

Description
Form Factor Form BI, 11 mm
Electrical Ratings 24 V AC ±20%, 24 V DC ±25%
Integrated Components LED indicator, Zener diode (Z-diode)
Thread Size M16 × 1.5
Housing Material Plastic, chemical- and oil-resistant
Mounting Type Field-wireable
Tightening Torque 0.4 Nm
Mounting Set M3
Protection Degree IP67 (inserted and screwed)
Operating Temperature -25 °C to +70 °C
Storage Temperature -40 °C to +70 °C
IO-Link Version V1.1
Port Class Class B
Operating Mode COM2 (38.4 kBaud)
Cycle Time 2.3 ms
Input Channels 8 digital inputs (PNP, Type 3, EN 61131-2)
Input Filter Time 1 ms
Input Delay Time Max. 8 ms (including IO-Link cycle time)
Output Channels 8 digital outputs (PNP, short-circuit and overload protected)
Output Current per Pin Max. 0.4 A
Actuator Supply (UA) 24 V DC, max. 4 A
Sensor Supply (US) 24 V DC, max. 100 mA
Housing Fully potted plastic
Mounting 2-hole screw mounting
Dimensions (H × W × D) 126 × 50 × 34.5 mm
Weight 0.2 kg
