6054713 | SICK SENSORS | UC30-214164 Ultrasonic Distance Sensor

₹ 32,724.00

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6054713

Original Equipment Manufacturer

SICK SENSORS

Description
Operating range, limiting range 350 mm ... 3,400 mm, 5,000 mm
Target Natural objects
Resolution ≥ 0.18 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2) 3)
Temperature compensation ✔
Response time 180 ms
Switching frequency 4 Hz
Output time 43 ms
Ultrasonic frequency (typical) 120 kHz
Dimensions (W x H x D)

62 mm x 62 mm x 33.2 mm 1)

62 mm x 62 mm x 32.7 mm 2)
Design Rectangular
Sending axis Straight
Housing material Plastic (PBT/PET, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 180 g
Connection type Male connector, M12, 5-pin



SICK SENSORS 6054713 UC30-214164 Ultrasonic Distance Sensor
SICK SENSORS

6054713 | SICK SENSORS | UC30-214164 Ultrasonic Distance Sensor

₹ 32,724.00
Operating range, limiting range 350 mm ... 3,400 mm, 5,000 mm
Target Natural objects
Resolution ≥ 0.18 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2) 3)
Temperature compensation ✔
Response time 180 ms
Switching frequency 4 Hz
Output time 43 ms
Ultrasonic frequency (typical) 120 kHz
Dimensions (W x H x D)

62 mm x 62 mm x 33.2 mm 1)

62 mm x 62 mm x 32.7 mm 2)
Design Rectangular
Sending axis Straight
Housing material Plastic (PBT/PET, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 180 g
Connection type Male connector, M12, 5-pin
