SPARECRUX is NOT an authorized distributor for SIEMENS

6ES7 288-3AR02-0AA0 | SIEMENS | S7-200 Smart, Analog Input SM AR02 RTD, 2x AI RTD Modules

₹ 8,365.84

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6ES7 288-3AR02-0AA0

Original Equipment Manufacturer

SIEMENS

Description
Manufacturer Siemens
Module Type / Product Type Designation SM AR02, AI RTD 2×16 bit
S7 Series S7-200 SMART
Supply Voltage (Rated) 24 V DC (-15 % / +20 %) :contentReference[oaicite:0]{index=0}
Power Consumption / Loss Typ. 1.5 W :contentReference[oaicite:1]{index=1}
Current Consumption ≈ 40 mA from 24 V; plus ≈ 80 mA from the backplane bus (5 V) :contentReference[oaicite:2]{index=2}
Number of Analog Inputs 2 inputs, for Resistance Thermometer (RTD) sensors :contentReference[oaicite:3]{index=3}
Supported Sensor Types / Ranges Resistance Thermometer types such as Pt100, Pt1000, Ni100, Ni1000, Cu10, etc., and ranges from ~ 0-48 Ω, up to ≈ 3000 Ω depending on type. :contentReference[oaicite:4]{index=4}
Resolution & Conversion Time 15 bits + sign; integration times parameterizable (10 / 16.67 / 20 / 100 ms) :contentReference[oaicite:5]{index=5}
Filtering / Noise Suppression Interference suppression for frequencies 10 / 50 / 60 / 400 Hz; digital smoothing / filtering available in configurable stages. :contentReference[oaicite:6]{index=6}
Physical Dimensions (W × H × D) 45 × 100 × 81 mm :contentReference[oaicite:7]{index=7}
Weight ≈ 0.15 kg :contentReference[oaicite:8]{index=8}
Reparameterization in RUN No :contentReference[oaicite:9]{index=9}
Compatible System / Bus Mounting SM bus for S7-200 SMART station modules :contentReference[oaicite:10]{index=10}
SIEMENS

6ES7 288-3AR02-0AA0 | SIEMENS | S7-200 Smart, Analog Input SM AR02 RTD, 2x AI RTD Modules

₹ 8,365.84
Manufacturer Siemens
Module Type / Product Type Designation SM AR02, AI RTD 2×16 bit
S7 Series S7-200 SMART
Supply Voltage (Rated) 24 V DC (-15 % / +20 %) :contentReference[oaicite:0]{index=0}
Power Consumption / Loss Typ. 1.5 W :contentReference[oaicite:1]{index=1}
Current Consumption ≈ 40 mA from 24 V; plus ≈ 80 mA from the backplane bus (5 V) :contentReference[oaicite:2]{index=2}
Number of Analog Inputs 2 inputs, for Resistance Thermometer (RTD) sensors :contentReference[oaicite:3]{index=3}
Supported Sensor Types / Ranges Resistance Thermometer types such as Pt100, Pt1000, Ni100, Ni1000, Cu10, etc., and ranges from ~ 0-48 Ω, up to ≈ 3000 Ω depending on type. :contentReference[oaicite:4]{index=4}
Resolution & Conversion Time 15 bits + sign; integration times parameterizable (10 / 16.67 / 20 / 100 ms) :contentReference[oaicite:5]{index=5}
Filtering / Noise Suppression Interference suppression for frequencies 10 / 50 / 60 / 400 Hz; digital smoothing / filtering available in configurable stages. :contentReference[oaicite:6]{index=6}
Physical Dimensions (W × H × D) 45 × 100 × 81 mm :contentReference[oaicite:7]{index=7}
Weight ≈ 0.15 kg :contentReference[oaicite:8]{index=8}
Reparameterization in RUN No :contentReference[oaicite:9]{index=9}
Compatible System / Bus Mounting SM bus for S7-200 SMART station modules :contentReference[oaicite:10]{index=10}
