7208B | NSK | Angular Ball Bearing

₹ 2,499.64

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

7208B

Original Equipment Manufacturer

NSK

Description

Specification Details
I.D. 40 mm
O.D. 80 mm
Width 18 mm
Raceway Ring Shape Angular Bearing (Single)
Bearing Type Open Type
Outer Ring Type Flat
Inner/Outer Ring Material Steel
Basic Dynamic Load Rating 32000 N
Specifications / Environment Standard
Precision (JIS) Grade 0
Load Direction Radial
Rolling Element Material Steel
Size Standards Metric System
Max. Allowable Rotational Speed 6700 rpm
Outer Ring With Outer Ring
Combination of Angular Contact Ball Bearings Single Row
Retainer Type Momi removing
Basic Load Rating: Static Load 23000 N
Clearance Sign CN (standard)
Preload Normal preload
Contact Angle 40°
Holder Symbol No
Symbol of Bearing Ring Shape No
Seal / Shield Symbols No
Precision Grade Symbol No
Symbol of Contact Angle B
Combination Symbol No
Preload Mark No
Special Configurations Code No
Bearing Type Symbol No
Type Symbol No
Material Symbol -
Spacer / Sleeve Symbol -
RoHS 10
NSK

7208B | NSK | Angular Ball Bearing

₹ 2,499.64
Specification Details
I.D. 40 mm
O.D. 80 mm
Width 18 mm
Raceway Ring Shape Angular Bearing (Single)
Bearing Type Open Type
Outer Ring Type Flat
Inner/Outer Ring Material Steel
Basic Dynamic Load Rating 32000 N
Specifications / Environment Standard
Precision (JIS) Grade 0
Load Direction Radial
Rolling Element Material Steel
Size Standards Metric System
Max. Allowable Rotational Speed 6700 rpm
Outer Ring With Outer Ring
Combination of Angular Contact Ball Bearings Single Row
Retainer Type Momi removing
Basic Load Rating: Static Load 23000 N
Clearance Sign CN (standard)
Preload Normal preload
Contact Angle 40°
Holder Symbol No
Symbol of Bearing Ring Shape No
Seal / Shield Symbols No
Precision Grade Symbol No
Symbol of Contact Angle B
Combination Symbol No
Preload Mark No
Special Configurations Code No
Bearing Type Symbol No
Type Symbol No
Material Symbol -
Spacer / Sleeve Symbol -
RoHS 10
