SPARECRUX is NOT an authorized distributor for WAGO

750-452 | WAGO | 2-Channel Analog Input Module, 0–20 mA, Differential

₹ 63,172.15

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-452

Original Equipment Manufacturer

WAGO

Description
Parameter Value
Signal type Current
Signal type (current) 0 … 20 mADC
Sensor connection 2 x (2-wire)
Input voltage (max.) 35 V
Signal characteristics Differential
Resolution 12 Bit
Input resistance (max.) 220 Ω
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Mounting type DIN-35 rail
Pluggable connector Fixed
Color Light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 0.815 MJ
Weight 50.5 g
Conformity marking CE
WAGO

750-452 | WAGO | 2-Channel Analog Input Module, 0–20 mA, Differential

₹ 63,172.15
Parameter Value
Signal type Current
Signal type (current) 0 … 20 mADC
Sensor connection 2 x (2-wire)
Input voltage (max.) 35 V
Signal characteristics Differential
Resolution 12 Bit
Input resistance (max.) 220 Ω
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Mounting type DIN-35 rail
Pluggable connector Fixed
Color Light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 0.815 MJ
Weight 50.5 g
Conformity marking CE
