A9N1P03C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breaker, 1 Pole, 3A, C Curve, 10kA

₹ 308.27

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

A9N1P03C

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Series Acti9 xC60
Poles 1‑Pole (Single Pole)
Rated Current (In) 3 A
Tripping Curve C‑Curve (thermal‑magnetic)
Rated Operational Voltage (Ue) 220‑240 V AC; up to 60 V DC
Breaking Capacity (Icu) 15 kA (IEC 60947‑2); 10 kA (IEC 60898‑1)
Service Breaking Capacity (Ics) 15 kA @ DC; ~7.5 kA @ AC
Magnetic Trip Limit ≈ 8 × In ± 20 %
Rated Insulation Voltage (Ui) 500 V AC
Impulse Withstand Voltage (Uimp) 6 kV
Mounting 35 mm DIN‑rail clip‑on
Terminal Type Screw‑clamp terminals, reversible line/load
Dimensions (H×W×D) 85 × 18 × 77.5 mm (2 pitches × 9 mm width)
Weight ≈ 0.115 kg
Electrical Durability ≈ 20,000 operations
Operating Temperature −30 °C to +70 °C
Protection Class IP20 (front)
Standards & Certifications IEC 60947‑2, IEC 60898‑1; IS/IEC 60898; Green Premium; RoHS/REACh compliant
