AE120-010 | APEX DYNAMICS | High Precision Gearboxes

₹ 92,648.75

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

AE120-010

Original Equipment Manufacturer

APEX DYNAMICS

Description

Category Specification
Primary Brand APEX Dynamics
Main Function Gearbox (Planetary; 1-stage)
Product Series AE / AER Series
Sub-range Name AE (Straight)
Technology 1-stage planetary reduction
Synthetic lubrication oil
Triple split collet input
Material Stainless Steel
Shape Straight
Mounting Mode All directions
Protection Class IP65
Sound / Noise Level 63 dB
Efficiency 97%
Mechanical Durability 20,000 hours
Nominal Torque 230 N·m / 169.64 ft·lb
Maximum Torque 690 N·m (Emergency stop)
Gear Ratio 1:10
Backlash 8 arcmin
Moment of Inertia 0.000257 kg·m²
Torsional Rigidity 25 N·m / arcmin
Maximum Radial Load 6100 N
Maximum Axial Load 3350 N
Rotational Speed Nominal: 4000 rpmMax: 8000 rpm
Temperature Range -10 °C to +90 °C
Net Width (Flange) 120 mm
Output Shaft With Key
Net Weight 6.9 kg
