SPARECRUX is NOT an authorized distributor for FERRAZ SHAWMUT

AJT80 | FERRAZ SHAWMUT | Fuse 80A

₹ 3,553.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

AJT80

Original Equipment Manufacturer

FERRAZ SHAWMUT

Description

Specification Value
Item Number AJT80
Description Fuse AJT - Class J - Time-delay 600VAC 400VDC 80A Blade SmartSpot® Amp-Trap 2000®
EAN/UPC Code 782001962661
Rated Voltage (AC UL) 600 V
Rated Voltage (DC UL) 400 V
Frequency 50/60 Hz
Ampere Rating 80 A
RoHS Compliant Yes
AC or DC AC/DC
Fuse Class Class J
Speed/Characteristic Time Delay
Mounting Clip or Bolted
AC Max I.R./Breaking Capacity 200 kA
Indication System Yes (SmartSpot®)
Connection/Terminal Material Tin-Plated Copper
Connection/Terminal Type Blade
Product Diameter 27 mm
Product Length 117.6 mm
Sell Pack Quantity 5 EA
Sell Pack Weight 0.5761 kg
Sell Pack Width 136.7 mm
Sell Pack Length 152.4 mm
Sell Pack Height 26.9 mm
FERRAZ SHAWMUT
