B5133-0 | TURCK | Actuator & Sensor Wireable M8×1 Female 3-Pin Connector, Straight, 75 VDC / 60 VAC

₹ 2,185.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

Original Equipment Manufacturer

TURCK

Description

Attribute Details
EAN 4047101458251
eCl@ss-Code (V5.1.4) 27279201 -/- Connectivity (accessories sensors)
Customs tariff number 85366990990
Country of origin DE
Weight 12 g
Application Signal
Connector A Female, M8 × 1, Straight
Number of pins 3
Connection mode Screw/clamp connection
Screw-in thread M11 × 0.75
Housing material Plastic, PBT
Coupling nut/screw material Die-cast Zinc, GD-Zn, Nickel-plated
External diameter of the cable 3.5…5 mm
Core cross-section/Clamping ability 0.14…0.5 mm²
Voltage 60 V
Current 4 A
Approvals cULus recognized
