BK3120 | BECKHOFF | PROFIBUS Economy Plus Bus Coupler

₹ 20,319.60

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

BK3120

Original Equipment Manufacturer

BECKHOFF

Description
Number of Bus Terminals 64 (255 with K-bus extension)
Max. number of bytes fieldbus 128 byte input and 128 byte output
Data transfer rates automatic detection up to 12 Mbaud
Bus interface 1 x D-sub 9-pin socket with shielding
Data transfer medium shielded copper cable, 2 x 0.25 mm²
Power supply 24 V DC (-15%/+20%)
Input current 70 mA + (total K-bus current)/4, 500 mA max.
Current supply K-bus 1750 mA
Power contacts max. 24 V DC/max. 10 A
Electrical isolation 500 V (power contact/supply voltage/fieldbus)
Weight approx. 170 g
Operating temperature -25…+60°C
